Fibre Reinforced Plastic (FRP): Why Fibreglass?

What fibre reinforced plastic is, and why it resists corrosion, stays watertight and installs quickly. These are the reasons Mullaly uses it for pump stations and water tanks.

Get a price

Tell us roughly what you need. A sales engineer replies within 2 business days.

Have drawings or a full spec? Use the detailed quote form, or call 02 4964 8270.

By sending you agree to our Privacy Policy.

What is fibre reinforced plastic (FRP)?

Fibre reinforced plastic (FRP) is a composite material made from glass fibre reinforcement set in a resin. The glass fibres give it strength, and the resin binds them together and forms the surface. The same FRP material goes by several names: fibreglass, GRP (glass reinforced plastic) and, in the United States, fiberglass reinforced plastic.

Mullaly uses premium grade vinyl ester resin, which resists the corrosive chemicals and gases found in sewage and wastewater. A Mullaly pump station wall is built up in layers: inner and external corrosion layers (0.5mm, vinyl ester resin with C-glass or synthetic tissue) either side of an E-glass structural backing layer. The solid wall is typically at least 20mm thick, with a corrosion barrier as standard. Large wet well shells are filament wound, with glass-fibre rovings fed onto a mandrel. Mullaly underground water tanks are made with premium resin with no fillers, and integral fibreglass ribs give them their strength.

Why FRP for pump stations and tanks

There are a number of reasons why fibreglass is the material of choice for sewage structures such as pump stations, wet wells, valve pits and manholes. The main benefits are summarised below, followed by a side-by-side comparison of a Mullaly FRP pump station and a concrete pump station.

Mullaly FRP pump station with integrated valve chamber being lowered by crane into the excavation at The Orchard

Benefits of a Mullaly fibreglass pump station

Factory manufactured

  • Mullaly pump stations are made as a single, one-piece unit in carefully controlled factory conditions
  • Each one complies with a design created by a registered practising composite engineer
  • Our workforce is skilled in the manufacturing process, with many decades of combined experience

Engineered for strength

  • Whether installed in a fully flooded hole or in a dry hole with no groundwater, Mullaly pump stations are designed for a wide range of site conditions
  • Designed to withstand varying ground and hydraulic pressures, as well as the pressures created by changing surface loads
  • This also means the unit can take rough handling on site

Low maintenance

The resins used to make Mullaly fibreglass resist the corrosive chemicals found in sewer and wastewater, unlike concrete.

  • Smooth walls reduce scum build-up
  • Resistant to abrasion from suspended grit
  • Resistant to chemical attack
  • Less scheduled maintenance

Quick, easy installation

  • Units are delivered to site near complete
  • Less need for skilled tradespeople on site
  • Supplied with comprehensive installation instructions, including ballast calculations to counter hydrostatic uplift, developed by a qualified engineer
  • Less on-site construction time

100% watertight

Watertight construction protects the environment. It prevents contamination of the surrounding water table, and stops surrounding groundwater getting in, so there is no unnecessary pumping and water treatment. This helps with Environment Protection Authority (EPA) pollution-control requirements.

Corrosion resistant and watertight

  • Fibreglass resists corrosion, which protects the services inside from the harsh corrosive conditions often found in wastewater structures
  • With its one-piece, factory-made design, a Mullaly wet well does not rely on sealants applied on site to be watertight
  • A one-piece, structurally strong Mullaly pump station is a watertight answer to what is often an expensive maintenance problem with concrete structures

Inside the Mullaly factory

Glass-fibre rovings feeding onto a large FRP wet well shell on the filament-winding mandrel for Stone Drive, Mackay

Filament winding, Stone Drive Mackay job, 2013

Finished green Mullaly Engineering FRP wet well on cradles in the factory awaiting client inspection

Factory inspection, Cairns job, 2014

Laminator trimming the flange of a fibreglass tank end on a work platform in the factory

Tank end fabrication, 2014

Fibreglass and concrete pump stations compared

The table below summarises some of the differences between a Mullaly FRP pump station and a concrete pump station.

FeatureMullaly fibreglass pump stationConcrete pump station
PackageDelivered as one complete unit, often a combo with an integral valve pit. No assembly on siteComes in sections joined on site, or is poured on site. Fit-out needs access to a confined space
OH&SNo fit-out on site, so little need to enter the station as a confined spaceLong assembly and heavy handling. Fit-out often in confined spaces
TimeCan be installed in a few hours on some projects, saving time and money and cutting the chance of wet weather affecting the jobLonger assembly. An in situ concrete station typically takes weeks to install, for example over six weeks on Sino Iron and Badu Island
WeightLightweight, which reduces OH&S risk and makes it easier to installHeavy handling increases OH&S risk and makes it harder to install
CorrosionVinyl ester resins resist the corrosive chemicals in sewageSteel in concrete corrodes from H2S gas and the sulphuric acid it produces. Needs an internal coating or liner
EngineeredEngineered for strength. Allows for ground movement with no structural fatigueGround movement can crack the concrete and break seals between sections
Life expectancy100-year design lifeCan be designed for 100 years, but often needs repair or refurbishment after early corrosion or erosion
Warranty30-year corrosion warranty, which we can back with a 30-year track record of installed pump stationsVaries, but rarely 30 years
MaintenanceLess maintenance, because smooth internal walls stay cleaner for longerRough walls need more frequent cleaning (without an internal liner)
WatertightOne sealed, single-unit constructionCan leak through cracks, joins between precast segments or poorly placed concrete
Remote locationsInstalled in some of the most remote places in AustraliaRemote sites often have no concrete supply, and moving heavy precast units long distances is difficult and costly
Quality controlMade in controlled factory conditions to an independent design by a registered practising composite engineerQuality of concrete placement varies with the experience of the crew

Fibreglass and concrete pump stations compared in detail

Mullaly fibreglass products

See the full range of Mullaly fibreglass pump stations, including sewage pump stations and stormwater pump stations, or our underground water tanks. For tanks, read fibreglass vs concrete water tanks. To see how they perform on site, read about our projects, including a pump station inspected 20 years after installation.
